Quality Medical Display PCB & PCBA manufacturer 4 layers ENIG 1OZ copper

Detail Specifications:

HDI PCB, High Frenquency PCB

Based on a variety of parameters, HF signals are reflected on circuit board, meaning that the impedance (dynamic resistance) varies with respect towards the sending component. To prevent such capacitive effects, all parameters must be exactly specified, and implemented with the highest amount of approach manage.

Vital for the impedances inhigh frequency printed circuit boardsare principally the conductor trace geometry, the layer buildup, along with the dielectric continuous (er) on the supplies applied.

HDI PCB Materials used for HF circuit boards

For many applications, it is sufficient to use FR4 material with an appropriate layer buildup. In addition, we process high-frequency materials with improved dielectric properties. These have a very low loss factor, a low dielectric constant, and are primarily temperature and frequency independent.

Additional favourable properties are high glass transition temperature, an excellent thermal durability, and very low hydrophilic rate.

We use (among others) Rogers or PTFE materials (for example, Teflon from DuPont) for impedance controlled high frequency circuit boards. Sandwich buildups for material combinations are also possible.

HDI PCB Specifications

• Base Material: FR4
• Number of Layers: 2 L
• Board Thickness: 1.6 mm
• Copper Thickness: 0.5 OZ to 7.0 OZ
• Min. Hole Size: 3mil (0.075mm)
• Min. Line Spacing: 3mil (0.075mm)
• Min. Line Width: 3mil (0.075mm)
• Surface Finishing: HASL lead free
• Solder Mask Color: Green
• Certificate: UL, ISO 9001, ISO 14001

HDI PCB Application

Our HDI PCB are ideal for many applicaitons, like communication industry, medical equipments, consumer electronics and automobile industry. We supply high-precision, high-density, double-sided and multilayer HDI PCB for mobile phones, computers, LED, etc.

Layers 4 Layers
Material FR-4 EM-825
Board Thickness 0.8mm
Copper Thickness 1oz
Surface Treatment ENIG
Soldmask & Silkscreen Green & White
Quality Standard IPC Class 2, 100% E-testing
Certificates TS16949, ISO9001, UL, RoHS

What KAZ Circuit can do for you:

PCB manufacturing (prototype, small to medium, mass production)
Components Sourcing
PCB Assembly/SMT/DIP

To get a full quotation of the PCB/PCBA, pls provide the information as below:

Gerber File, with detail specification of the PCB
BOM List (Better with excel fomart)
Photoes of the PCBA (If you have done this PCBA before)

Company Informaiton:

ZR Circuit is a professional PCB manufacturer from China since 2007, also provide PCB Assembly service for our customers. Now with about 300 employees. Certified with ISO9001,TS16949, UL, RoHS. We are confident to provide you quality products with factory-directed price within the fastest delivery time!

Manufacturer Capacity:

Capacity Double Sided: 12000 sq.m / month
Multilayers: 8000sq.m / month
Min Line Width/Gap 4/4 mil (1mil=0.0254mm)
Board Thickness 0.3~4.0mm
Layers 1~20 layers
Material FR-4, Aluminum, PI
Copper Thickness 0.5~4oz
Material Tg Tg140~Tg170
Max PCB Size 600*1200mm
Min Hole Size 0.2mm (+/- 0.025)
Surface Treatment HASL, ENIG, OSP

SMT Capacity

Assembly Lines Equipments Fit Components Sizes Fit PCB Sizes Supported Components Theoretical CPH Fit for Products
Min Max Min Max Chip IC
1
DSP-1008+YS24+

YV100XGP+YG12F+JT NS1000

0.2×

0.1mm

50×

50mm
Pitch=

0.2mm

50×

50mm

410×

460mm

200 Tape
20 Tray 110000 3300 Phone, Motherboard, Industrial Control board, Laptop, GPU, etc.
2
DSP-1008+MX200+MX200+

MX200+MX200P+JT NS1000

0.4×

0.2mm

45×

150mm

50×

50mm

410×

460mm

280 Tape

22 Tray

75000 1200 Motherboard,
Laptop,
small&medium GPU, etc.
3
DSP-1008+MX400+MX200+

MX200+MX200P+JT NS1000

0.4×

0.2mm

50×

50mm

50×

50mm

410×

460mm

280 Tape

20 Tray

107000 1200
4
DSP-1008+MX400+MX200+

MX200+MX200P+JT NS1000

0.4×

0.2mm

50×

50mm

50×

50mm

410×

460mm

280 Tape

20 Tray

107000 1200
5
JKD600AA+

MX200+MX200P

0.4×

0.2mm

45×

150mm

50×

50mm

410×

460mm

120 Tape

22 Tray

35000 1200
General Digital Products, small & medium cardboard BOT

Photoes of this
