1. pcb file with parts list provided by customers
2. pcb boards made, pcb parts purchased by us
3. pcb boards with parts assembled
4.Electrinic Testing pcb or PCBA
We can copy pcb or PCBA if customers send samples to us
We are a profesional flexible printed board manufacturer in China, can supplier lots design and multilayer pcb to you. Pls contact with me from below system if you have any interesting in our products.
This is 12 layer pcb with top and bottom picture. We could offer 12 layer pcb and 12 layer pcb and pcb assembly service for our customers.
Technical requirements:
Layer:12 layer
Thickness:0.8mm
Finish coating:
Solder Mask:Green
Material: Fr-4
Min.Hole Size:0.1mm(4mil)
Min.Line width/Space:0.1mm/0.1mm(4mil/4mil)
Special Technique:Blind &buried via+Impedance control
Reference-Our Production Capability for Rigid PCB:
1 Layer: 1-30
2 Board finished thickness:0.21mm-7.0mm
3 Material: FR-4, CEM-1, CEM-3, High TG, FR4 halogen Free, Rogers
4 Max.finished board size:23*25(580*900mm)
5 Min.drilled hole size:3mil(0.075mm)
6 Min.Line width:3mil(0.075mm)
Min.Line spacing:3mil(0.075mm)
7 Surface finish/treatment: HASL/HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating.
8 Copper thickness:0.5-7.0 oz
9 Solder mask color: Green/yellow/black/white/red/blue
10 Copper thickness in hole: >25.0 um(>1mil)
11 Inner packing: Vaccum packing/Plastic bag
Outer packing: Standard carton packing
12 Shape tolerance:±0.13
Hole tolerance:PTH: ±0.076 NPTH: ±0.05
13 Cerificate: UL.ISO9001.ISO14001.SGS.ROHS.
14 Special requirements:Buried and blind vias+Controlled impedance+BGA
15 Profilling:Punching.Routing.V-CUT.Beveling
16 Provides OEM Services to all sorts of printed circuit board assembly as we as electronic encased products.
Product/Service: PCB, PCBA, printed circuit board, PCB assemble, SMT, FPCB, FPC, Rigid and Flex board, Rigid Printed circuit board.
flexible circuit board
1) Material: flexible, tg140
2) Certificate: UL, ISO, TS16949;
3) T/T,Paypal,Western Union
1.pcb certificate:UL/SGS/Rohs/ISO9001
2.OEM service offered
3.competitive price
4.timely delivery
Our Production Capability for PCB
| Layer | 1 to 28 layers |
| Material type | FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers |
| Board thickness | 0.21mm to 7.0mm |
| Copper thickness | 0.5 OZ to 7.0 OZ |
| Copper thickness in hole | >25.0 um (>1mil) |
| Size | - Max. Board Size: 23 × 25 (580mm×900mm) |
| - Min. Drilled Hole Size: 3mil (0.075mm) |
| - Min. Line Width: 3mil (0.075mm) |
| - Min. Line Spacing: 3mil (0.075mm) |
| Surface finishing | HASL / HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating |
| Solder Mask Color | Green/Yellow/Black/White/Red/Blue |
| Tolerance | - Shape tolerance: ±0.13 |
| - Hole tolerance: PTH: ±0.076 NPTH: ±0.05 |
| PCB Packing | - Inner packing: Vacuum packing / Plastic bag |
| - Outer packing: Standard carton packing |
| Certificate | UL, ISO 9001, ISO 14001 |
| Special requirements | Buried and blind vias+controlled impedance +BGA |
| Profiling | Punching, Routing, V-CUT, Beveling |
| Provides OEM services to all sorts of printed circuit board assembly as well as electronic encased products |
1) Min. Trace width: 0.004"
2) Min. Space between trace: 0.004"
3) Min. Hole size: 0.012"
4) Thickness tolerance:
A) Single sided: 0.005"
B) Double sided: 0.010"
5) Base materials: Polyimide and polyester
6) Conductor (copper thickness): 0.5oz., 10oz. And 20oz. (RA and ED copper)
7) Cover-layer: Polyimide and polyester (solder mask printing is available)
8) Adhesive material: Epoxy, acrylic and polyester
9) Stiffener materials: FR-4, mylar and polyimide
10) Surface finishes: Flash gold plating, selective gold plating and solder plating.
