| 03009987-01 | Centering sleeve |
| 03010004-04 | Main Distributor |
| 03010005-05 | Sub Distributor |
| 03010008-05 | CABLE TREE RIBBON CABLE |
| 03010010-02 | FUSE SET POWER SUPPLY |
| 03010085S06 | PICK-UP WINDOW / X8 |
| 03010185S01 | ROTARY SLIDE / COMPONENTS DISPOSAL X8 |
| 03010197-01 | ISO 7045 - M2 x 4-A2-50-H |
| 03010209-01 | ISO 7045 - M2.5 x 6-A2-50-H |
| 03010313S01 | Mechanical Z-axis guide/C+P20 |
| 03010315S01 | Maglev MWA120-0064 |
| 03010329S01 | HOLDER FEEDER SLIDE SPRING/X8 |
| 03010342S02 | Ratchet compl. / Roll X8 |
| 03010352-01 | Tension spring d=0,63* D=5,6* Lo=23,3 |
| 03010354S02 | Ratchet compl./ Roll X12 |
| 03010415S01 | Tension Spring Z-051GX |
| 03010476-01 | Adjusting USA/JAPAN SIPLACE expert with special tools highly recommended, risk of damage and warranty losses Voltage test required |
| 03010482-01 | LINE FILTER |
| 03010496-01 | CABLE FOR MOTOR MTC 2 |
| 03010513-01 | CONTACTOR 3RT1015-1JB42 |
| 03010517-01 | SWITCH 3LD2 |
| 03010565-01 | CALIBRATION PART VERSION 3 |
| 03010576-03 | PCB/Interface 1-Wire RS232 |
| 03010577-01 | PCB / 1-Wire Hub INTERFACE |
| 03010578-01 | PCB / 1-Wire Hub HEADINTERFFACE C500 |
| 03010605-03 | CAN-CARD CPCI-COM168 |
| 03010615-01 | CABLE:SVGA-CONNECTION 0,3m |
| 03010619-01 | CABLE: SVGA EXTENSION-CABLE 1m |
| 03010670-02 | Hotlink - Filter |
| 03010773-02 | SLOT BASE |
| 03010865-01 | COVER PLATE Y-MAGNET RAIL X-HS |
| 03010933-02 | SECURITY SWITCH TOWER 1 |
| 03010934-02 | SECURITY SWITCH TOWER 2 |
| 03011249-01 | ELECTROLYTIC CAPACITOR 47000uF/63V |
| 03011577S01 | CARTRIDGE WITH MULTEMP PS NO. 2 |
| 03011582-02 | FEEDER UNLOCK DEVICE 40-way The feeder unlock can be repaired when pins are bent or defect. see 03088220 ETP Feeder Entriegelung and SX service manual. |
| 03011583-02 | NOZZLE ADAPTER COMPL./ STANDARD SEAL |
| 03011592-01 | Blanking plug |
| 03011622-01 | CPCI RS232 Karte |
| 03011658-01 | PARTITION PLATE /TAPEREEL CONTAINER COMP |
| 03011694-01 | JIG VHS |
| 03011719-01 | Template TwinHead |
| 03011739S03 | Energy-Data interface cpl. /X-Series |
| 03011816-02 | DRIVER COMPLETE |
| 03012002S02 | Intermediate distributor carrier /C+P |
| 03012011-01 | NOZZLE TYPE 518 complete / Twin-Head |
| 03012034-01 | NOZZLE TYPE 519 complete / Twin-Head |
| 03012036-01 | NOZZLE TYPE 516 complete / Twin-Head |
| 03012042-01 | NOZZLE TYPE 517 complete / Twin-Head |
| 03012057S04 | PICK UP WINDOW / X 12 |
| 03012076S01 | Vacuum Generator for Vacuum Pump DLM2 |
| 03012097-01 | CABLE SET / C+P20 |
| 03012175S01 | HOLDER / CLIP PICK-UP WINDOW X12 |
| 03012203S01 | C+P Head sleeve 12 star, modified for placement of comp. up 10.7mm. |
| 03012350-01 | Screw / Bearing Pick-Up Window X24 X72 |
| 03012357S01 | LEAF SPRING / TAPE INPUT X 8 |
| 03012415S01 | C+P head sleeve 6 star, modified for placement of comp. up 10.7mm. |
| 03012416S01 | LEAF SPRING / TAPE INPUT X 12 |
| 03012425-01 | SLIDING GUIDE / FRONT L17 |
| 03012522-02 | DISTANCE SENSOR |
| 03012539-01 | Retrof.kit Discharge Choke Coil |
| 03012564-03 | SERVO AMPLIFIER TBS/3S1 |
| 03012565S01 | SERVO AMPLIFIER TDS120A3Z-01 |
| 03012658-01 | WASTE CONTAINER /COMPONENTSCARRIAGE |
| 03012683-01 | PRESSION SPRING D-027 |
| 03012691-01 | ISO 7380-M3 x 6-10.9 verz.,schw.chrom. |
| 03012730-01 | Barcode Reader SICK CLV 422 |
| 03012823-01 | SLOTTED HOLE STRIP |
| 03013015-02 | Verteiler Bestückkopf |
| 03013018S01 | HOSE/DP VACUUM C+P |
| 03013022-01 | Distance Bolt Type B i/a-M2.5x7-A2 |
| 03013038-01 | AUTOMATIC CIRCUITE BREAKER 5SX2 / 3pol / 13A-AC |
| 03013061S01 | air filter complete P+P-Modul |
| 03013091S01 | ANTI-GLARE SHIELD COMPLETE DP C+P20 |
| 03013103-01 | NOZZLE TYPE 1034 COMPLETE |
| 03013143S01 | MODULE /SENSORIC HEAD PLATE CPL. |
| 03013300-01 | NOZZLE TYPE 1011 |
| 03013303-01 | NOZZLE TYPE 1014 |
| 03013307-02 | NOZZLE TYPE 1001 COMPL. 1,4x0,9 |
| 03013331-01 | ABSORBABILITY RUBBER/CABLE DRAG CHAIN |
| 03013425-01 | NOZZLE TYPE 1033 COMPLETE |
| 03013445S01 | LEVER COMPLETE |
| 03013450-01 | PNEUMATIC SPRING 8/22 330N |
| 03013451-01 | PNEUMATIC SPRING 8/22 350N |
| 03013459S03 | Y-drive compl. (primary) Part must be replaced by a SIPLACE expert because of health and safety risks because of removal of gantry magnet |
| 03013461-01 | STOP RIGHT SIDE FOR Y-MOTOR |
| 03013462-01 | HOLDER BERO Y-AXIS BASE UNIT LEFT SIDE |
| 03013486-01 | COVER MIDDLE PART CONNECTION |
| 03013488-01 | SCHMERSAL AZ335- ACTUATOR Security switches and actuators are part of the safety provisions of the SIPLACE placement machines and are only to be used in situ in the location and positions provided for them. Impropper usage can result in serious personal or machine damage. Impropper usage of the placement machines includes - the operation of the machine with the safety installations out of order or removed - the bridging of the safety installations By impropper usage of SIPLACE placement machines ASM Assembly Systems GmbH <(>&<)> Co. KG does not take any liability for damages occuring or guaranty the faultless and functional operation of the components and assemblies |
| 03013648-01 | STROKE LIMITATION 3.2 mm |
| 03013678S03 | FBG /EDIF sec. IrDA-Board |
| 03014091-01 | NOZZLE WITHDRAWING TOOL Typ 5xx kpl. |
| 03014258-01 | CLIP / C+P |
| 03014273S02 | Tape Support 3x8mm SL |
| 03014286S01 | PCB/ PORTAL IDENTIFICATION 1-WIRE |
| 03014327-01 | NOZZLE TYPE 1032 COMPL. |
| 03014331-01 | NOZZLE TYPE 1036 COMPLETE |
| 03014336-01 | NOZZLE TYPE 1133 COMPLETE |
| 03014406-05 | PPW COMPLETE /C+P20 |
| 03014407S02 | PORTALSYSTEM / COMPLETE R |
| 03014449S05 | COMPONENT-CAMERA C+P(Type28) 18x18 digital RK |
| 03014457-01 | TRANSPORTATION LOCK / X-AXIS |
| 03014616S01 | HOSE/EXHAUST AIR C+P20 |
| 03014643-01 | UNIT MOUNTING RAIL 3 |
| 03014654S01 | HOSE / ADAPTER EXHAUST AIR C+P 20 |
| 03014658-01 | STAR LABEL 1-6 |
| 03014659-01 | STAR LABEL 1-12 |
| 03015194-01 | NOZZLE TYPE 1035 compl |
| 03015222-01 | NOZZLE TYPE 1235 COMPLETE |
| 03015384-01 | NOZZLE TYPE 1135 compl./ 2 part Nozzle |
| 03015388S05 | PCB / 1-WIRE PPW C+P |
