| 00364674-01 | COMPRESSION SPRING 0,4*5,4*10,5 V2A |
| 00364715S01 | COMPRESSION SPRING 0,63x5,63x26 |
| 00364726-01 | TRANSMISSION 4 |
| 00364782-01 | LASER LIGHT BARRIER TRANSM.BB1 |
| 00364783-01 | LASER LIGHT BARRIER TRANSM.BB2 |
| 00364813-02 | SERVO AMPLIFIER PCB TBS200/15Y2 |
| 00364847S01 | Toothed Belt Synchroflex 2,5T5/1160 |
| 00364861-02 | STOP RIGHT SIDE 1 |
| 00364867-01 | Guide rail, right-hand side, laser |
| 00364870-01 | Guide rail left side 3 |
| 00364873-02 | Slideway lining |
| 00364890-01 | ACTUATOR COMPLETE Exchange by trained staff |
| 00364925-01 | Jointing clamp for cutting |
| 00364926-01 | Add.Package, Modular Headboard |
| 00364951-01 | PORTAL-FAN Y-AXIS HS-50 OPTIONAL |
| 00364991-01 | BK-MOD422-C310 strain relief 10pole |
| 00365001-02 | LIMIT SWITCH MOUNTING TUB |
| 00365016-02 | CAN-CONVERSION TRANSPORT TSP-CAN |
| 00365108-02 | LIMIT SWITCH WIDTH ADJUSTMENT 1 |
| 00365109-02 | LIMIT SWITCH WIDTH ADJUSTMENT 2 |
| 00365111-01 | Seal for Foil Insert gear |
| 00365262-01 | COVER PLUG FOR INA GUIDE RAIL TKVD 25 G3 |
| 00365263S01 | GUIDE RAIL HS50 |
| 00365283-01 | BOLT M4*55 i/i 6kt7 |
| 00365543-04 | CONTROL UNIT COMPLETE CONVEYOR |
| 00365544-04 | CONTROL UNIT COMPL. PCB DUAL CONVEYOR |
| 00365548-02 | Motor cable / sensor cable track 1 |
| 00365720-01 | Motor cable placement area 1 |
| 00365765-01 | Limit switch for width adjustment |
| 00365772-01 | LS-RECIFER Modul Placement 1 |
| 00365774-01 | LS-RECIFER Modul Placement 2 |
| 00365775-01 | Limit Switch Width Adjustment 1 |
| 00365776-01 | Limit Switch Width Adjustment 2 |
| 00365777-01 | Limit Switch Mounting Tub |
| 00366104-01 | TR-GREASE NIPPLE |
| 00366174-01 | CARTOUCHE FOR GREASE |
| 00366224-01 | Transmitter piece 1 |
| 00366346-01 | CABLE HOLDER BACK PANEL Exchange by trained staff |
| 00366391-01 | STOPPER PCB ADJUSTMENT |
| 00366392-01 | Stopper PCB Direction short way |
| 00366567-01 | Battery pack |
| 00366568-01 | LC-Unit ( lubrication cartridge) |
| 00366692-02 | Mounting sheet |
| 00366694-01 | RETROFIT KIT FOR COMP. FLAP HS50 |
| 00366803S03 | MVS340-6 VME V2321M calibr. |
| 00366857-02 | Deflection pulley, ungeared,injec.mold. |
| 00366858-02 | Deflection pulley, geared (inject.mold.) |
| 00366881-01 | GUIDE BELT INPUT BAND |
| 00366882-01 | GUIDE BELT OUTPUT BAND |
| 00366932-01 | X-BRAKE |
| 00366964-01 | FUSE g 6*32 /T6,3A |
| 00367013-02 | Y-BRAKE OUTSIDE |
| 00367071-01 | Oil Dispenser z-Axis STRUCTVIS GHD 7ml |
| 00367142S04 | COMP.SENSOR SP-12 COMPL. |
| 00367174-02 | MOTOR WITH SYNCHRONIZING DISK |
| 00367237-01 | GAS PRESSURE OPERATED SPRING 15N Hub 150 |
| 00367238-01 | Fillister head screw PT, H KA40*18 |
| 00367241-02 | CABLE HS50: COMP.BELT FLAP SECTOR 1 and 3 |
| 00367242-02 | CABLE HS50: BELT-FLAP Sector 2 and 4 |
| 00367243-01 | SAFETY SWITCH Serie ST14 1S+1Ö |
| 00367244-01 | ACTUATOR DIRECTLY ST 14-B1 Security switches and actuators are part of the safety provisions of the SIPLACE placement machines and are only to be used in situ in the location and positions provided for them. Impropper usage can result in serious personal or machine damage. Impropper usage of the placement machines includes - the operation of the machine with the safety installations out of order or removed - the bridging of the safety installations By impropper usage of SIPLACE placement machines ASM Assembly Systems GmbH <(>&<)> Co. KG does not take any liability for damages occuring or guaranty the faultless and functional operation of the components and assemblies |
| 00367289-01 | Hexagon shaft SW8x536 |
| 00367328-02 | Belt Support |
| 00367468S02 | LAN - CARD KSP-COM294 2x LAN 6x HUB |
| 00367737-02 | SILENCER SES 14 H |
| 00367758S02 | COLLECT<(>&<)>PLACE HEAD DLM2-6 / without cam. |
| 00367760S01 | Vacuum Measuring Board Assy DLM2 |
| 00367768S03 | Valve Drive, Reject Circuit, DLM2 DLM3 |
| 00367770S02 | COLLECT <(>&<)> PLACE HEAD DLM2-12 / without camera |
| 00367793S03 | BLISTER UNIT DLM2/DLM3 |
| 00367848S01 | Vacuum Generator for Vacuum Pump |
| 00367881S01 | POWER SUPPLY FOR MONITOR |
| 00367977-01 | Cover conversion board assembly tray |
| 00367979-01 | Cover 2 (cable channel) |
| 00367984-01 | Cable channel 44x30x550 |
| 00368025-01 | CRASH-PC-BOARD S-27 HM |
| 00368063-01 | Clamp Panduit CC S12-S08 D3,1 b 8,2 |
| 00368075S03 | Valve Drive, Placement Circuit, DLM2/DLM3 |
| 00368077S01 | Star-drive digital DLM2 |
| 00368123S02 | DISTRIBUTOR CAP PAS-LX-6 complete |
| 00368211S02 | DISTRIBUTOR CAP complete PAS-LX-12 |
| 00368247-01 | Flow-control valve H-QS-6 |
| 00368271-01 | Sensor PCB FIXING |
| 00368272-01 | SENSOR PCB PRESSURE BB1 |
| 00368273-01 | SENSOR PCB PRESSURE BB2 |
| 00368279-01 | Tube Di 32 |
| 00368291-01 | PCB POSITION CETECTION GLAS WITH RING MACRO60S |
| 00368328-01 | CABLE SPLICE DETECT: TC POWER OUTLET |
| 00368349-01 | GUIDE RAIL 3 LEFT SIDE |
| 00368385-01 | STOPPER-BASE UNIT COMPL. |
| 00368562-01 | TEST PCB 0201 |
| 00368782-01 | MAIN SWITCH FOR POWER UNIT S4/F4/S23/S25/F5HM |
| 00368931S01 | PLUG (NEUTRAL) |
| 00369014-03 | VALVE WITH CABLE ADJUSTMENT UNIT 1 |
| 00369016-01 | CYLINDER SWITCH ADJUSTING WIDTH |
| 00369017-01 | Cylinder switch width adjustment 2 |
| 00369018-01 | BERO ADJUSTING UNIT 1 |
| 00369205-01 | Adjusting LaserConveyor |
| 00369294-01 | ELASTOMER SPRING D20x8,5 90 Shore A |
| 00369418-04 | Adjusting Unit 3 Width Adjustment SM |
| 00369424-01 | Adapter 151E cpl. |
| 00369638-01 | CABLE CYLINDER SWITCH OPT. LONG BCP |
| 00369662-01 | Toothed Belt Brecoflex 12T5/3245 |
| 00369717-01 | DU-tape |
| 00369741-01 | SPRING COUPLING F.PRIMARY SHAFT |
| 00369755-01 | Cable HS50, Modular Head |
| 00369783-01 | Retrofit Kit -Komponent Level Indicator |
| 00369860-01 | CABLE S2X/FX MODULAR HEAD/DCA CAMERA |
| 00370046-01 | LIGHT BARRIER TRANSM. INPUT |
| 00370049-01 | LIGHT BARRIER TRANSM. OUTPUT |
| 00370050-01 | LIGHT BARRIER RECEIVER INPUT |
| 00370061-01 | LIGHT BARRIER RECEIVER APPLIC. BAND |
| 00370062-01 | LIGHT BARRIER RECEIVER OUTPUT |
| 00370063S02 | LIGHT BARRIER TRANSM. INPUT |
| 00370064-03 | Light barrier transm. placement belt 1 |
| 00370065-02 | LIGHT BARRIER TRANSM. MIDDLE BAND |
| 00370066-01 | LIGHT BARRIER TRANSM. APPLIC.BAND 2 |
| 00370066-03 | Light barrier transm. placement belt 2 |
| 00370067-02 | LIGHT BARRIER TRANSM. OUTPUT BAND |
| 00370068-01 | LIGHT BARRIER RECEIVER INPUT BAND |
| 00370069-01 | LIGHT BARRIER RECEIVER APPLIC.BAND 1 |
| 00370070-01 | LIGHT BARRIER RECEIVER MIDDLE BAND |
| 00370071-01 | LIGHT BARRIER RECEIVER APPLIC.BAND 2 |
| 00370072-01 | LIGHT BARRIER RECEIVER OUTPUT BAND |
| 00370132-01 | DOOR LEFT SIDE COMPL.(S20/F4) |
| 00370133-01 | DOOR RIGHT SIDE COMPL.(S20/F4) |
| 00370137-01 | Twisted-Pair-Cable RJ45 Kat. 5e 0,5m gy |
| 00370176-02 | Light Barrier, Transmitter, Input Belt |
| 00370177-04 | Ligth barrier transmitter placem. belt 1 |
| 00370178-02 | Light Barrier Transmitter Intermediate |
| 00370179-03 | Ligth barrier transmitter placem. belt 2 |
| 00370180-02 | Light Barrier,Transmitter,Output Belt |
| 00370202-01 | Light Barrier Recifer INPUT |
| 00370203-01 | Light Barrier Recifer PLACEMENT 1 |
| 00370204-01 | Light Barrier Recifer Intermediate |
| 00370205-01 | Light Barrier Recifer Placement 2 |
| 00370206-01 | Light Barrier Recifer OUTPUT |
| 00370239-01 | IEC-Interface Linux-Rechner (PCI-GPIB) |
| 00370298-01 | Sensor PC-Board-Clamping BB1 |
| 00370299-01 | Sensor PC-Board-Clamping BB2 |
| 00370321-02 | SENSOR GUIDE RAIL |
| 00370323-01 | SENSOR BOW |
| 00370324-02 | HOLDER SENSOR GUIDE RAIL |
| 00370349-01 | Protection mat conversion board basic as |
| 00370385-01 | Laser Light Barrier Transm.modul BB1 cpl. |
| 00370386-01 | Laser Light Barrier Transm.modul BB2 cpl. |
| 00370392-04 | Holder |
| 00370396-01 | STOP LEFT SIDE 2 |
| 00370691-01 | BELT MEASURING STRIPE |
| 00370710-01 | BRASS BRUSHER |
